SIGMA CINE LENS 24MM T1.5 FF F/AP (METRIC)

Be the first to review this product

KD999.000
Product code: 0085126934057

Availability: In stock

Highlights:

- Covers Full-Frame Format
- ARRI PL Mount
- T1.5 to T16 Aperture Range
- Geared Focus and Iris Control Rings
- Clickless Iris Ring
- 180° Focus Rotation
- 9-Blade Iris
- Select Luminescent Lens Markings
- Lens Scale Marked in Meters
Add to Wish List
Add to Compare

Details

The Sigma 24mm T1.5 FF High Speed Prime Lens (Meters) is part of Sigma's High Speed Prime lens family, featuring acclaimed optical designs from their Global Vision lens initiative. Features include 6-8K resolution, a fast T1.5 maximum aperture, a compact, lightweight form, and focus marks in meters. The installed ARRI PL mount ensures compatibility with industry-standard cinema cameras.

This 24mm lens shares the same physical diameter as the other lenses in the set while maintaining identical focus and iris gear positioning with the entire lens set, relative to the mount. The included support foot also attaches in the same spot on all lenses, so you won't have to move your lens support after changing lenses. All High Speed Prime lenses also share the same 95mm front diameter. Similar physical attributes across the lens line makes fitting lens accessories such as matte boxes, follow focuses, lens supports, and lens control motors easier and less time consuming. For mounting filters without a matte box, this lens also features an 82mm filter thread to accept readily available screw-on filters.

Lens Design and Testing

Introduced with the Global Vision initiative, Sigma's A1 MTF testing, using a 46 megapixel Foveon sensor, analyzes each lens before it leaves the factory, ensuring that the lens performs as intended and provides sharp images on high-resolution sensors. Advanced computer-aided design of these lenses enables Sigma to minimize flare and ghosting even before manufacturing. All these steps bring improved quality and consistency to Sigma's manufacturing.

Optical Qualities

Though many lenses that prioritize sharpness sacrifice the appearance of out-of-focus elements, Sigma's High Speed Prime lenses are designed to not compromise on bokeh, rendering sharp in-focus images and soft bokeh. Additionally, all Sigma High Speed Prime lenses are color matched. With color-matched lenses, shots taken with different lenses can utilize the same color correction, saving time in post-production.

Build Quality

For durability, the outer shell of the lens is manufactured from lightweight yet durable metal. The tightly sealed exterior resists both water and dust ingress, similar to Sigma's Sports lens line. The focus and iris rings both feature silent end-stops using resin dampening. The end of the focus travel will have a solid feel, yet won't disrupt quiet scenes. Cine-style push-on lens caps are included to protect the front element when the lens is not in use.



Additional Information

Send inquiry? No
Technical Specifications
Focal Length 24mm
Lens Mount ARRI PL
Format Full Frame
Image Circle 43.3 mm
Maximum T-Stop T1.5
Minimum T-Stop T16
Diagonal Angle of View Full Frame: 73.7°
Super35: 54.3°
APS-C (1.5x): 52.6°
Minimum Focus Distance from Image Plane 0.82' / 0.25 m
Optical Design Not Specified by Manufacturer
Iris Blades 9
Gear MOD & Pitch Focus: 0.8 MOD / 32 Pitch
Iris: 0.8 MOD / 32 Pitch
Front Diameter 95 mm
Filter Thread 82 mm
Focus Scales Metric
Focus Rotation 180°
Iris Rotation 60°
Electronic Communication No
Lens Support Lens Support Foot with 1/4"-20 Mounting Thread
Tripod Mounting Thread 1/4"-20
Dimensions (W x H) Not Specified by Manufacturer
Length 3.43" / 87 mm
Weight 2.26 lb / 1025 g
